Panasonic PT-MZ20KLBE WUXGA 20,000lm Laser Projector - Black

Panasonic PT-MZ20KLBE WUXGA 20,000lm Laser Projector - Black


Regular price $33,999.00
Regular price Sale price $33,999.00
ON SALE! Sold out
Inc. GST

Found a better deal? Request a Price Match Here!

View full details

Panasonic PT-MZ20KLBE WUXGA Laser Projector: Engineered for Professionals, by Professionals

No Lens is included with this projector, please select the required lens in the optional accessories section.
This projector is ordered in when required, typical lead time is 1 week.

Utilising a cutting-edge laser light source, the Panasonic PT-MZ20KLBE WUXGA 20,000lm Laser Projector - White offers an impressive 20,000 ANSI Lumens. With a variety of compatible lenses available, this top-of-the-line LCD projector is unmatched in versatility and a popular choice among projector options.

Key Features & Specifications

  • WUXGA 1920 x 1200 16:10
  • 20,000 ANSI Lumens
  • 3,000,000:1 Contrast
  • 23.0kg Weight
  • 42 / 36db(eco) Fan Noise
  • 5 Year/10,000hr Warranty
  • 5 Year/10,000hr Laser Warranty
  • Est. Laser Life up to 20,000hrs
  • 2x HDMI Connections
  • SDI Connection
  • Digital Link Connection
  • Horizontal & Vertical Keystone
  • Vertical Lens Shift +/-60%
  • Horizontal Lens Shift +/-20%
  • Powered Lens Shift
  • Powered Zoom & Focus
  • 360 Degree Installation (v+h axis)
  • Portrait Projection
  • Optional Lenses (no lens is included)
Panasonic PT-MZ20KLBE small and light

Ultra Quiet Operation Allows Viewers to Concentrate on Your Presentation

The Panasonic PT-MZ20KLBE is one of the worlds quietest projectors in this brightness range. Not only does it keep participants focused, it also contributes to an improved sound environment for applications such as hybrid conferences. When a quieter environment is required, noise level can be further reduced by setting the projector to QUIET Mode. This helps create an environment where all viewers can concentrate on the presentation.

Pure White Generator Delivers High Brightness and Rich Colour

Pure White Generator, developed by Panasonic Connect, contributes to rich colour reproduction at high brightness of 20,000 lm. Efficient light collection uses a multi-reflection system to minimize loss of light-source energy noticeable with conventional systems. It achieves an optimal color balance without sacrificing brightness for realistic and accurate color expression.

Panasonic PT-MZ20KLBE


World’s Smallest, Lightest, and Quietest 20,000 lm1 LCD Projector

Introducing the smallest, lightest, and quietest LCD laser projector in its class with up to 20,000 lm1, compact 23 kg3 (50.7 lbs) body, and quiet 42 dB4 operation. Optimized optical engine delivers a 25 % increase in brightness over the 16,000 lm PT-MZ16KL from the same body size, ensuring clear visibility in well-lit spaces.

Long-Life Energy-Saving Design Minimizes Problems

Multi-Laser Drive Engine and Backup Input enable continuous projection even in the event of trouble, and no light-source or filter maintenance is required for 20,000 hours. The series efficiently delivers high brightness with MZ20KL achieving the lowest power consumption in its class for sustainable operation.

Dynamic Contrast NX Realizes a New Dimension of Light and Dark Control

Dynamic Contrast NX, a further evolution of Dynamic Contrast, uses a newly developed video-scene analysis circuit to recognize differences in brightness and darkness more precisely than before.

Panasonic Dynamic Contrast

Delivering up to 20,000 lm5 on AC 100–240 V, a World First

PT-MZ20K Series is the industry’s first9 20,000 lm-class projector to deliver full brightness on AC 100–240 V power, eliminating need to install a high-voltage power supply. It supports NFC function10, optional lenses including ET-EMU100 Ultra-Short Throw Zoom Lens, and preactivated upgrade kits for Geo Pro11.

Light, Bright, Quiet, and Harmonious

As the smallest and lightest 20,000 lm LCD laser projector in its class, the MZ20KLBE installs flexibly almost anywhere and delivers bright, immersive images in a wide range of applications, from conferences to edutainment. Its sophisticated body styling harmonizes with the spatial environment while quiet 36 dB2 operation limits distractions, ideal for hybrid meeting rooms, museums, or lecture halls.

Perfectly Balanced Brightness and Colour

Together with high-efficiency optical engine for immersive high-contrast images in well-lit rooms, the MZ20KLBE features Pure White Generator, an original technology that minimizes loss of light energy and balances rich colour and high brightness. Dynamic Contrast NX includes new scene-recognition circuitry that detects light and dark areas of the image more precisely, while Detail Clarity Processor 4 sharpens text edges for clear visibility.

Geometric Adjustment Corrects Trapezoidal Distortion and Curved Screens

With built-in Geometric Adjustment, various distortions on the screen can be corrected via remote control. In addition to trapezoidal distortion resulting from angled projection, Curved Screen Correction fixes distortion caused by projection onto curved surfaces. Corner Correction allows the user to specify four screen corners, such as the upper right and lower right, for correction. Screen proportions can be maintained and corrections can be saved as data.

Panasonic Geometric Adjustment

Eco-Friendly Energy-Saving Design

The MZ20KLBE is highly efficient, with it consuming less energy than any projector in its class for highly sustainable daily operation. Light-source and filter replacement is extended to 20,000 hours, reducing waste. The projector is liquid cooled and features a dustproof structure for stable operation. Multi-Laser Drive Engine limits brightness loss should a diode fail, while Backup Input function maintains image display if the primary signal is interrupted.

Other Features

  • Supports 21:9 input signals
  • Supports Art-Net DMX, PJLink™, Crestron Connected™ V2, Crestron XiO Cloud™, Extron XTP®, and IPv612
  • Direct Power Off function
  • Quick Startup and Quick Off
  • DICOM Simulation Mode
  • Multi-Screen Support System
  • Multi-Unit Brightness and Color Control
  • Waveform Monitor function
  • Power management system

What's in the Box

  • Panasonic PT-MZ20KLBE Projector (no lens incl.)
  • Remote Control
  • Power Cord

What you may need

  • Projector Lens
  • HDMI Cable
  • Projector Screen
  • Projector Mount
  • Wireless Dongle
  • HDBaseT Transmitter
Projector type LCD
LCD Panel
Panel size 25.4 mm (1.0 in) diagonal (16:10 aspect ratio)
2,304,000 (1920 x 1200 pixels)
Light source Laser diode
Light output 20,000 lm
Time until light output declines to 50 % 20,000 hours (NORMAL/QUIET)
Resolution WUXGA (1920 x 1200 pixels)
Contrast ratio 3,000,000:1 (Full On/Full Off) (When [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] set to [3].)
Screen size (diagonal) 80-600 inches (Depending on Lens)
Center-to-corner zone ratio 85 %
Lens Optional (no lens included with this model)
Lens shift Vertical - ±60 % (+50 %, -20 % with ET-EMU100, ±40 % with ET-EMW200, ±50 % with ET-EMW300) (powered)
Horizontal - ±20 % (±19 % with ET-EMW200) (powered)
Keystone correction range Vertical: ±45 ° (±5 ° with ET-EMU100, ±14 ° with ET-EMW200/ET-EMW300, ±22 ° with ET-EMW400/ET-EMW500), Horizontal: ±40 ° (±0 ° with ET-EMU100, ±8 ° with ET-EMW200/ET-EMW300, ±15 ° with ET-EMW400/ET-EMW500).
When [VERTICAL KEYSTONE] and [HORIZONTAL KEYSTONE] are used simultaneously, correction cannot be made exceeding a total of 55 °.
SDI In BNC x 1: 3G/HD-SDI input
HDMI In HDMI 19-pin x 2 (Compatible with HDCP 2.3, Deep Color, 4K/60p signal input5), CEC supported
SERIAL/MULTI PROJECTOR SYNC IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
SERIAL/MULTI PROJECTOR SYNC OUT D-sub 9-pin (male) x 1 for link control (RS-232C compliant)
SERIAL IN D-sub 9-pin (female) x 1 for external control (RS-232C compliant)
SERIAL OUT D-sub 9-pin (male) x 1 for link control (RS-232C compliant)
REMOTE 1 IN D-sub 9-pin (female) × 1 for external control (parallel)
REMOTE 2 IN M3 x 1 for wired remote control
REMOTE 2 OUT M3 x 1 for link control (for wired remote control)
DIGITAL LINK RJ-45 x 1 for network and DIGITAL LINK connection (video/network/serial control) (HDBaseT™ compliant), 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net, HDCP 2.3, Deep Color, 4K/60p signal input5 )
LAN RJ-45 x 1 for network connection, 10Base-T, 100Base-TX (Compatible with PJLink™ [Class 2], Art-Net)
DC OUT USB connector (Type A) x 1 for power supply (Output: 5 V / 2 A)
USB USB connector (Type A) x 1 for optional AJ-WM50 Series Wireless Module, for USB memory
Power supply AC 100–240 V, 50/60 Hz
Power consumption*7 MAXIMUM 1100 W (11.2–4.6 A) (1120 VA)
NORMAL 1050 W (AC 100–120 V), 1000 W (AC 200–240 V)
QUIET 630 W (AC 100–120 V), 610 W (AC 200–240 V)
Operation noise2 42 dB (NORMAL), 36 dB (QUIET)
Dimensions (W x H x D) Approx. 650 x 185 x 440 mm (25 19/32˝ x 7 9/32˝ x 17 5/16˝) (excluding feet and protrusions), 650 x 211 x 440 mm (25 19/32˝ x 8 5/16˝ x 17 5/16˝) (excluding protrusions, feet at shortest position)
Weight Approx. 23.0 kg (50.7 lbs)
Operating environment Operating temperature: 0–45 °C (32–113 °F)9, operating humidity: 10–80 % (no condensation)
Applicable software Logo Transfer Software, Multi Monitoring & Control Software, Early Warning Software, Geometry Manager Pro, Projector Network Setup Software, Smart Projector Control for iOS/Android™
