Epson EB-L690SE 6,000lm LCD 4Ke Short Throw Laser Projector

Epson EB-L690SE Large Venue 4Ke Short Throw Laser Projector

Key Features & Specifications

• 4Ke 1920 x 1200x2 16:10
• 6000 ANSI Lumens
• 5,000,000:1 Contrast
• 9.3kg Weight
• 36 / 26db(eco) Fan Noise
• 5 Year/ 20,000hr Warranty
• 5 Year/ 20,000hr Laser Warranty
• Est. Laser Life up to 30,000hrs

• 0.5-0.7 Short Throw Ratio
• Horizontal & Vertical Keystone
• Vertical Lens Shift (-50%, +50%)
• Horizontal Lens Shift (+/- 20%)
• 1.4x Zoom
• 2x HDMI Connection
• 360° Projection
• Portrait Projection
• HDBaseT Compatible
• USB to laptop Connection
• Instant Off

Throw Distance Chart
(Throw Ratio: 0.50-0.7:1)

Experience ultra bright and compact projectors with pro‑level features.

An updated fleet of projectors that are designed to fit within many environments including meeting rooms, classrooms, immersive experiences, and golf simulators.

Key Features

• Ultra bright, true-to-life images – 3-chip 3LCD technology and 6,000 lumens of equal colour and white brightness.
• WUXGA with 4K Enhancement – The EB-L690SE features 4K Enhancement Technology, which displays double HD resolution on-screen for a visibly sharper, more detailed picture even at close viewing distances
• Large, versatile display options – easily create displays up to 500" diagonal in 16:10, plus ultra wide 16:6 and 21:9 aspect ratios for enhanced content display and visibility
• Simplified installation – wide vertical and horizontal lens shift, 3 different options of throw ratio ranges that together can display between 0.5 to 2.2 throw ratio coverage, 360-degree mounting, built-in geometric correction tools and a universal VESA mounting pattern
• Low maintenance – up to 30,000-hour laser light source and air filter in Extended Mode
• Wireless networking and content sharing – optional Wi-Fi® 6/6E allows for fast, reliable wireless connectivity for screen casting, along with direct connection to the cloud-based service, Epson Projector Management Connected, and WPA 3-enterprise security
• Built-in NFC – helps reduce installation time of multiple projectors; read and write setting information using the Epson Projector Configuration Tool App
• Optional attachable PixAlign camera – adds powerful multi-projector tools including screen matching6, auto color calibration, blending assist for super wide displays and simple stacking without an external PC
• Over-the-air updates – allows user to optionally be alerted when a Firmware update is available and apply remotely


Laser Light Source

Experience astonishing quality and reliability with Epson’s laser light source technology. The newly designed laser light source and advanced electrostatic filter offers fit and forget reliability to keep maintenance to a minimum.

4K Enhancement

The Epson L690SE delivers high-precision images with 4K Enhancement (4KE) technology. Upscale 1080p content with 4KE, which shifts pixels diagonally by 0.5 pixels to double the resolution, for crisp and high-definition images.

Brilliant images in any setting

Powered by 3LCD technology and Epson’s laser optical engine, the Epson L690SE series is capable of producing white light and colour light output of 6,000 lumens in WUXGA resolution, delivering captivating images in virtually any venue. While the light weight and compact size of these projectors enable them to be carried from room to room, they are also capable of highly visible images thanks to high brightness and a superior 5,000,000:1 contrast ratio.

Large image size

While conventional panels are limited to a pre-determined height and width, projectors have no such constraints. With the image size expanding up to 500”, your audience can easily read and understand the information you’re sharing.

Super Resolution with Detail Enhancement

Get a crisper and sharper image with advanced image features on the EB-L700 Series. Super-resolution defines edges for standard and HD content, while Detail enhancement refines surface detail for true-to-life images. With advanced digital processing, visibility of image displays such as small letters and patterns improves and the sharp edges create crisper images for a more immersive experience.

ADVANCED INSTALLATION FEATURES

Manual Lens Shift, Zoom and Focus

The manual lens shift covers a wide range, offering a great deal of flexibility when installing the projector.

HDBaseT and Diverse Connectivity

Cutting-edge HDBaseT technology means just one single CAT-5/6 cable carries Full HD video, audio, network and control commands up to 100 metres to accommodate large venues. No need for additional cables, signal repeaters or added labour.

360 Degree Projection

The Epson L690SE can be rotated 360° in any direction for off-axis positioning flexibility. As a result, they can be used for a wide range of applications, such as projecting on the ceiling or floor, or as part of a rear-projection system. Epson technology keeps the projector running without compromising performance or causing overheating.

Compact design

Weighing around 9 kg, the Epson L690SE series projectors boast a compact and lightweight design. They offer exceptional flexibility and easy installation.

Edge Blending

Enhance the experience with seamless panoramic, multi-screen images that blend edges by matching colour and brightness perfectly, even in areas that overlap.

Colour Uniformity

Keep images consistent and maintain images that have become uneven over time between multiple projectors with manual colour correction function.

Epson Projector Professional Tool (EPPT)

Setup multiple projectors straight out of the box with new large venue application software. Epson Professional tool allows you to adjust and control images projected on a network with high-end projector setup features such as geometry correction, image layout adjustment and edge blending. Exclusively bundled to Epson laser projectors, large scale presenting has become much easier and flexible with automation.
